Telenco AADE0750

Helical dead-end aluminum (short spans < 70m)
Capacity: 7.5 - 8.5mm

Description:
The helical dead-ends are used for installation of All Dielectric Self Sup porting (ADSS) optical
cables over spans up to 70m.
They consist of preformed assembled wires in one layer and are installed directly over the
ADSS cable.
Gripping material is applied on internal part of helical dead ends to assure the perfect
contact with cable sheath.
A C type thimble should be used to protect the dead-end loop against wear.
